GENERAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
0 to +40oC |
Operating Humidity |
15 to 95% RH |
|
Storage Temperatures |
-20 to +85oC |
Storage Humidity |
5 to 95% RH |
|
Hi-Pot Test |
MTBF |
||
|
Hi-Pot |
3000V AC |
MTBF |
40,000Hours at 25oC |
|
EMISSSION |
SAFETY |
||
|
EMI/EMC |
EMC/C-tick/FCC |
Safety Approvals |
UL/CUL/GS/SAA/PSE/ |
|
GREEN POWER |
Safety Compliant |
UL 60950/EN 60950/ |
|
|
CEC/ErP/MEPS |
|||
|
ELECTRICAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Input |
Output |
||
|
Input Voltage Range |
90-264V AC |
Output Voltage |
3 - 50V DC |
|
Input Frequency |
47-63Hz |
Output Current |
3A(24VA max) |
|
Input Current |
0.6A(max) |
Output Tolerance |
5% |
|
|
|
Ripple & Noise |
100mVp-p max |
|
|
|
Efficiency |
>60% |
OUTPUT SPECIFICATIONS
SERIES NO. :3SI24
SWITCHING ADAPTOR
DESKTOP-INLET SOCKET
24 SERIES
|
PART NO. |
OUTPUT |
|
|
VOLT |
CURRENT (max) |
|
|
3SI24-0603000 |
3.0V |
3.00A |
|
3SI24-0653000 |
3.5V |
3.00A |
|
3SI24-0703000 |
4.0V |
3.00A |
|
3SI24-0753000 |
4.5V |
3.00A |
|
3SI24-0703000 |
5.0V |
3.00A |
|
3SI24-0753000 |
5.5V |
3.00A |
|
3SI24-0603000 |
6.0V |
3.00A |
|
3SI24-0653000 |
6.5V |
3.00A |
|
3SI24-0703000 |
7.0V |
3.00A |
|
3SI24-0753000 |
7.5V |
3.00A |
|
3SI24-0803000 |
8.0V |
3.00A |
|
3SI24-0852820 |
8.5V |
2.82A |
|
3SI24-0902660 |
9.0V |
2.66A |
|
3SI24-0952520 |
9.5V |
2.52A |
|
3SI24-1002400 |
10.0V |
2.40A |
|
3SI24-1052280 |
10.5V |
2.28A |
|
3SI24-1102180 |
11.0V |
2.18A |
|
3SI24-1152080 |
11.5V |
2.08A |
|
3SI24-1202000 |
12.0V |
2.00A |
|
3SI24-1251920 |
12.5V |
1.92A |
|
3SI24-1301840 |
13.0V |
1.84A |
|
3SI24-1351770 |
13.5V |
1.77A |
|
3SI24-1401710 |
14.0V |
1.71A |
|
3SI24-1451650 |
14.5V |
1.65A |
|
3SI24-1501600 |
15.0V |
1.60A |
|
3SI24-1551540 |
15.5V |
1.54A |
|
3SI24-1601500 |
16.0V |
1.50A |
|
3SI24-1651450 |
16.5V |
1.45A |
|
3SI24-1701410 |
17.0V |
1.41A |
|
3SI24-1751370 |
17.5V |
1.37A |
|
3SI24-1801330 |
18.0V |
1.33A |
|
3SI24-1851290 |
18.5V |
1.29A |
|
3SI24-1901260 |
19.0V |
1.26A |
|
3SI24-1951230 |
19.5V |
1.23A |
|
3SI24-2001200 |
20.0V |
1.20A |
|
3SI24-2051170 |
20.5V |
1.17A |
|
3SI24-2101140 |
21.0V |
1.14A |
|
3SI24-2151110 |
21.5V |
1.11A |
|
3SI24-2201090 |
22.0V |
1.09A |
|
3SI24-2251060 |
22.5V |
1.06A |
|
3SI24-2301040 |
23.0V |
1.04A |
|
3SI24-2351020 |
23.5V |
1.02A |
|
3SI24-2401000 |
24.0V |
1.00A |
|
3SI24-2450970 |
24.5V |
0.97A |
|
3SI24-2500960 |
25.0V |
0.96A |
|
3SI24-2550940 |
25.5V |
0.94A |
|
3SI24-2600920 |
26.0V |
0.92A |
|
PART NO. |
OUTPUT |
|
|
VOLT |
CURRENT (max) |
|
|
3SI24-2650900 |
26.5V |
0.90A |
|
3SI24-2700880 |
27.0V |
0.88A |
|
3SI24-2750870 |
27.5V |
0.87A |
|
3SI24-2800850 |
28.0V |
0.85A |
|
3SI24-2850840 |
28.5V |
0.84A |
|
3SI24-2900820 |
29.0V |
0.82A |
|
3SI24-2950810 |
29.5V |
0.81A |
|
3SI24-3000800 |
30.0V |
0.80A |
|
3SI24-3050780 |
30.5V |
0.78A |
|
3SI24-3100770 |
31.0V |
0.77A |
|
3SI24-3150760 |
31.5V |
0.76A |
|
3SI24-3200750 |
32.0V |
0.75A |
|
3SI24-3250730 |
32.5V |
0.73A |
|
3SI24-3300720 |
33.0V |
0.72A |
|
3SI24-3350710 |
33.5V |
0.71A |
|
3SI24-3400700 |
34.0V |
0.70A |
|
3SI24-3450690 |
34.5V |
0.69A |
|
3SI24-3500680 |
35.0V |
0.68A |
|
3SI24-3550670 |
35.5V |
0.67A |
|
3SI24-3600660 |
36.0V |
0.66A |
|
3SI24-3650650 |
36.5V |
0.65A |
|
3SI24-3700640 |
37.0V |
0.64A |
|
3SI24-3750640 |
37.5V |
0.64A |
|
3SI24-3800630 |
38.0V |
0.63A |
|
3SI24-3850620 |
38.5V |
0.62A |
|
3SI24-3900610 |
39.0V |
0.61A |
|
3SI24-3950600 |
39.5V |
0.60A |
|
3SI24-4000600 |
40.0V |
0.60A |
|
3SI24-4050590 |
40.5V |
0.59A |
|
3SI24-4100580 |
41.0V |
0.58A |
|
3SI24-4150570 |
41.5V |
0.57A |
|
3SI24-4200570 |
42.0V |
0.57A |
|
3SI24-4250560 |
42.5V |
0.56A |
|
3SI24-4300550 |
43.0V |
0.55A |
|
3SI24-4350550 |
43.5V |
0.55A |
|
3SI24-4400540 |
44.0V |
0.54A |
|
3SI24-4450530 |
44.5V |
0.53A |
|
3SI24-4500530 |
45.0V |
0.53A |
|
3SI24-4550520 |
45.5V |
0.52A |
|
3SI24-4600520 |
46.0V |
0.52A |
|
3SI24-4650510 |
46.5V |
0.51A |
|
3SI24-4700510 |
47.0V |
0.51A |
|
3SI24-4750500 |
47.5V |
0.50A |
|
3SI24-4800500 |
48.0V |
0.50A |
|
3SI24-4850490 |
48.5V |
0.49A |
|
3SI24-4900480 |
49.0V |
0.48A |
|
3SI24-4950480 |
49.5V |
0.48A |
|
3SI24-5000480 |
50.0V |
0.48A |
 |
 |
 |
 |
 |
 |
