GENERAL SPECIFICATION |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
-10 to +30oC |
Operating Humidity |
10 to 90% RH |
|
Storage Temperatures |
-10 to +70oC |
Storage Humidity |
5 to 95% RH |
|
Hi-Pot Test |
Safety |
Compliance With |
|
|
Primary to Core |
3750V AC, one second |
CB |
IEC 60950 |
|
Primary to Secondary |
3750V AC, one second |
||
|
ELECTRICAL SPECIFICATION |
|||
|---|---|---|---|
|
INPUT |
OUTPUT |
||
|
Input Voltage |
220V AC |
Output Voltage |
1.4-12V DC |
|
Input Frequency |
50Hz |
Output Tolerance (Load) |
5% |
|
Output Current |
0.05-1.2A |
||
|
Output Watt |
6VA max |
||
LINEAR ADAPTOR
WALLMOUNT
EI 41 AC TO DC (REGULATED) ADAPTOR
INPUT:220V AC 50Hz
OUTPUT SPECIFICATION
|
1.4-7.5V |
9-12V |
|---|
|
9V |
12V |
|
|
|
|
|
|
0.65A |
SF41-0900650RK |
|
|
|
|
|
|
0.60A |
SF41-0900600RK |
|
|
|
|
|
|
0.50A |
SF41-0900500RK |
SF41-1200500RK |
|
|
|
|
|
0.40A |
SF41-0900400RK |
SF41-1200400RK |
|
|
|
|
|
0.30A |
SF41-0900300RK |
SF41-1200300RK |
|
|
|
|
|
0.20A |
SF41-0900200RK |
SF41-1200200RK |
|
|
|
|
|
1.4V |
3V |
4.5V |
5V |
6V |
7.5V |
|
|
1.20A |
|
SF41-0301200RK |
SF41-0451200RK |
|
|
|
|
1.10A |
|
SF41-0301100RK |
SF41-0451100RK |
|
|
|
|
1.00A |
SF41-0141000RK |
SF41-0301000RK |
SF41-0451000RK |
SF41-0501000RK |
SF41-0601000RK |
|
|
0.90A |
SF41-0140900RK |
SF41-0300900RK |
SF41-0450900RK |
SF41-0500900RK |
SF41-0600900RK |
|
|
0.80A |
SF41-0140800RK |
SF41-0300800RK |
SF41-0450800RK |
SF41-0500800RK |
SF41-0600800RK |
SF41-0750800RK |
|
0.70A |
SF41-0140700RK |
SF41-0300700RK |
SF41-0450700RK |
SF41-0500700RK |
SF41-0600700RK |
SF41-0750700RK |
|
0.60A |
SF41-0140600RK |
SF41-0300600RK |
SF41-0450600RK |
SF41-0500600RK |
SF41-0600600RK |
SF41-0750600RK |
|
0.50A |
SF41-0140500RK |
SF41-0300500RK |
SF41-0450500RK |
SF41-0500500RK |
SF41-0600500RK |
SF41-0750500RK |
|
0.40A |
SF41-0140400RK |
SF41-0300400RK |
SF41-0450400RK |
SF41-0500400RK |
SF41-0600400RK |
SF41-0750400RK |
|
0.30A |
SF41-0140300RK |
SF41-0300300RK |
SF41-0450300RK |
SF41-0500300RK |
SF41-0600300RK |
SF41-0750300RK |
|
0.20A |
SF41-0140200RK |
SF41-0300200RK |
SF41-0450200RK |
SF41-0500200RK |
SF41-0600200RK |
SF41-0750200RK |
|
0.10A |
|
|
|
SF41-0500100RK |
SF41-0600100RK |
|
|
0.05A |
|
|
|
SF41-0500050RK |
SF41-0600050RK |
|
 |
 |
 |
 |
 |
 |
