LINEAR ADAPTOR
DESKTOP
EI 41 AC TO DC (REGULATED) ADAPTOR
Input:120V AC 60Hz
|
ELECTRICAL SPECIFICATION |
|||
|---|---|---|---|
|
INPUT |
OUTPUT |
||
|
Input Voltage |
120VAC |
Output Voltage |
1-25V DC |
|
Input Frequency |
60Hz |
Output Tolerance (Load) |
5% |
|
|
|
Output Current |
0.05-1.2A |
|
|
|
Output Watt |
6VA max |
|
GENERAL SPECIFICATION |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
-10 to +30oC |
Operating Humidity |
10 to 90% RH |
|
Storage Temperatures |
-10 to +70oC |
Storage Humidity |
5 to 95% RH |
|
Hi-Pot Test |
Safety |
Compliance With |
|
|
Primary to Core |
1800VAC, one second |
UL/CUL |
UL 1310/ |
|
Primary to Secondary |
1800VAC, one second |
||
OUTPUT SPECIFICATION
|
1-3.5V |
4-6.5V |
7-9.5V |
10-12.5V |
13-15.5V |
16-18.5V |
19-21.5V |
22-24.5V |
25V |
|---|
|
22V |
22.5V |
23V |
23.5V |
24V |
24.5V |
|
|
0.2.5A |
SF41T-2200250RU |
SF41T-2250250RU |
SF41T-2300250RU |
SF41T-2350250RU |
SF41T-2400250RU |
|
|
0.2A |
SF41T-2200200RU |
SF41T-2250200RU |
SF41T-2300200RU |
SF41T-2350200RU |
SF41T-2400200RU |
SF41T-2450200RU |
|
0.1A |
SF41T-2200100RU |
SF41T-2250100RU |
SF41T-2300100RU |
SF41T-2350100RU |
SF41T-2400100RU |
SF41T-2450100RU |
|
0.05A |
SF41T-2200050RU |
SF41T-2250050RU |
SF41T-2300050RU |
SF41T-2350050RU |
SF41T-2400050RU |
SF41T-2450050RU |
|
19V |
19.5V |
20V |
20.5V |
21V |
21.5V |
|
|
0.3A |
SF41T-1900300RU |
SF41T-1950300RU |
SF41T-2000300RU |
|
|
|
|
0.2.5A |
SF41T-1900250RU |
SF41T-1950250RU |
SF41T-2000250RU |
SF41T-2050250RU |
SF41T-2100250RU |
SF41T-2150250RU |
|
0.2A |
SF41T-1900200RU |
SF41T-1950200RU |
SF41T-2000200RU |
SF41T-2050200RU |
SF41T-2100200RU |
SF41T-2150200RU |
|
0.1A |
SF41T-1900100RU |
SF41T-1950100RU |
SF41T-2000100RU |
SF41T-2050100RU |
SF41T-2100100RU |
SF41T-2150100RU |
|
0.05A |
SF41T-1900050RU |
SF41T-1950050RU |
SF41T-2000050RU |
SF41T-2050050RU |
SF41T-2100050RU |
SF41T-2150050RU |
|
16V |
16.5V |
17V |
17.5V |
18V |
18.5V |
|
|
0.35A |
SF41T-1600350RU |
SF41T-1650350RU |
SF41T-1700350RU |
|
|
|
|
0.3A |
SF41T-1600300RU |
SF41T-1650300RU |
SF41T-1700300RU |
SF41T-1750300RU |
SF41T-1800300RU |
SF41T-1850300RU |
|
0.2A |
SF41T-1600200RU |
SF41T-1650200RU |
SF41T-1700200RU |
SF41T-1750200RU |
SF41T-1800200RU |
SF41T-1850200RU |
|
0.1A |
SF41T-1600100RU |
SF41T-1650100RU |
SF41T-1700100RU |
SF41T-1750100RU |
SF41T-1800100RU |
SF41T-1850100RU |
|
0.05A |
SF41T-1600050RU |
SF41T-1650050RU |
SF41T-1700050RU |
SF41T-1750050RU |
SF41T-1800050RU |
SF41T-1850050RU |
|
13V |
13.5V |
14V |
14.5V |
15V |
15.5V |
|
|
0.45A |
SF41T-1300450RU |
|
|
|
|
|
|
0.4A |
SF41T-1300400RU |
SF41T-1350400RU |
SF41T-1400400RU |
SF41T-1450400RU |
SF41T-1500400RU |
|
|
0.35A |
SF41T-1300350RU |
SF41T-1350350RU |
SF41T-1400350RU |
SF41T-1450350RU |
SF41T-1500350RU |
SF41T-1550350RU |
|
0.3A |
SF41T-1300300RU |
SF41T-1350300RU |
SF41T-1400300RU |
SF41T-1450300RU |
SF41T-1500300RU |
SF41T-1550300RU |
|
0.2A |
SF41T-1300200RU |
SF41T-1350200RU |
SF41T-1400200RU |
SF41T-1450200RU |
SF41T-1500200RU |
SF41T-1550200RU |
|
0.1A |
SF41T-1300100RU |
SF41T-1350100RU |
SF41T-1400100RU |
SF41T-1450100RU |
SF41T-1500100RU |
SF41T-1550100RU |
|
0.05A |
SF41T-1300050RU |
SF41T-1350050RU |
SF41T-1400050RU |
SF41T-1450050RU |
SF41T-1500050RU |
SF41T-1550050RU |
|
10V |
10.5V |
11V |
11.5V |
12V |
12.5V |
|
|
0.6A |
SF41T-1000600RU |
|
|
|
|
|
|
0.55A |
SF41T-1000550RU |
SF41T-1050550RU |
SF41T-1100550RU |
SF41T-1150550RU |
|
|
|
0.5A |
SF41T-1000500RU |
SF41T-1050500RU |
SF41T-1100500RU |
SF41T-1150500RU |
SF41T-1200500RU |
|
|
0.45A |
SF41T-1000450RU |
SF41T-1050450RU |
SF41T-1100450RU |
SF41T-1150450RU |
SF41T-1200450RU |
SF41T-1250450RU |
|
0.4A |
SF41T-1000400RU |
SF41T-1050400RU |
SF41T-1100400RU |
SF41T-1150400RU |
SF41T-1200400RU |
SF41T-1250400RU |
|
0.3A |
SF41T-1000300RU |
SF41T-1050300RU |
SF41T-1100300RU |
SF41T-1150300RU |
SF41T-1200300RU |
SF41T-1250300RU |
|
0.2A |
SF41T-1000200RU |
SF41T-1050200RU |
SF41T-1100200RU |
SF41T-1150200RU |
SF41T-1200200RU |
SF41T-1250200RU |
|
0.1A |
SF41T-1000100RU |
SF41T-1050100RU |
SF41T-1100100RU |
SF41T-1150100RU |
SF41T-1200100RU |
SF41T-1250100RU |
|
0.05A |
SF41T-1000050RU |
SF41T-1050050RU |
SF41T-1100050RU |
SF41T-1150050RU |
SF41T-1200050RU |
SF41T-1250050RU |
|
7V |
7.5V |
8V |
8.5V |
9V |
9.5V |
|
|
0.8A |
SF41T-0700800RU |
SF41T-0750800RU |
|
|
|
|
|
0.7A |
SF41T-0700700RU |
SF41T-0750700RU |
SF41T-0800700RU |
SF41T-0850700RU |
|
|
|
0.65A |
SF41T-0700650RU |
SF41T-0750650RU |
SF41T-0800650RU |
SF41T-0850650RU |
SF41T-0900650RU |
|
|
0.6A |
SF41T-0700600RU |
SF41T-0750600RU |
SF41T-0800600RU |
SF41T-0850600RU |
SF41T-0900600RU |
SF41T-0950600RU |
|
0.5A |
SF41T-0700500RU |
SF41T-0750500RU |
SF41T-0800500RU |
SF41T-0850500RU |
SF41T-0900500RU |
SF41T-0950500RU |
|
0.4A |
SF41T-0700400RU |
SF41T-0750400RU |
SF41T-0800400RU |
SF41T-0850400RU |
SF41T-0900400RU |
SF41T-0950400RU |
|
0.3A |
SF41T-0700300RU |
SF41T-0750300RU |
SF41T-0800300RU |
SF41T-0850300RU |
SF41T-0900300RU |
SF41T-0950300RU |
|
0.2A |
SF41T-0700200RU |
SF41T-0750200RU |
SF41T-0800200RU |
SF41T-0850200RU |
SF41T-0900200RU |
SF41T-0950200RU |
|
0.1A |
SF41T-0700100RU |
SF41T-0750100RU |
SF41T-0800100RU |
SF41T-0850100RU |
SF41T-0900100RU |
SF41T-0950100RU |
|
0.05A |
SF41T-0700050RU |
SF41T-0750050RU |
SF41T-0800050RU |
SF41T-0850050RU |
SF41T-0900050RU |
SF41T-0950050RU |
|
4V |
4.5V |
5V |
5.5V |
6V |
6.5V |
|
|
1.2A |
SF41T-0401200RU |
SF41T-0451200RU |
|
|
|
|
|
1.1A |
SF41T-0401100RU |
SF41T-0451100RU |
SF41T-0501100RU |
|
|
|
|
1.0A |
SF41T-0401000RU |
SF41T-0451000RU |
SF41T-0501000RU |
SF41T-0551000RU |
SF41T-0601000RU |
|
|
0.9A |
SF41T-0400900RU |
SF41T-0450900RU |
SF41T-0500900RU |
SF41T-0550900RU |
SF41T-0600900RU |
SF41T-0650900RU |
|
0.8A |
SF41T-0400800RU |
SF41T-0450800RU |
SF41T-0500800RU |
SF41T-0550800RU |
SF41T-0600800RU |
SF41T-0650800RU |
|
0.7A |
SF41T-0400700RU |
SF41T-0450700RU |
SF41T-0500700RU |
SF41T-0550700RU |
SF41T-0600700RU |
SF41T-0650700RU |
|
0.6A |
SF41T-0400600RU |
SF41T-0450600RU |
SF41T-0500600RU |
SF41T-0550600RU |
SF41T-0600600RU |
SF41T-0650600RU |
|
0.5A |
SF41T-0400500RU |
SF41T-0450500RU |
SF41T-0500500RU |
SF41T-0550500RU |
SF41T-0600500RU |
SF41T-0650500RU |
|
0.4A |
SF41T-0400400RU |
SF41T-0450400RU |
SF41T-0500400RU |
SF41T-0550400RU |
SF41T-0600400RU |
SF41T-0650400RU |
|
0.3A |
SF41T-0400300RU |
SF41T-0450300RU |
SF41T-0500300RU |
SF41T-0550300RU |
SF41T-0600300RU |
SF41T-0650300RU |
|
0.2A |
SF41T-0400200RU |
SF41T-0450200RU |
SF41T-0500200RU |
SF41T-0550200RU |
SF41T-0600200RU |
SF41T-0650200RU |
|
0.1A |
SF41T-0400100RU |
SF41T-0450100RU |
SF41T-0500100RU |
SF41T-0550100RU |
SF41T-0600100RU |
SF41T-0650100RU |
|
0.05A |
SF41T-0400050RU |
SF41T-0450050RU |
SF41T-0500050RU |
SF41T-0550050RU |
SF41T-0600050RU |
SF41T-0650050RU |
|
1V |
1.5V |
2V |
2.5V |
3V |
3.5V |
|
|
1.2A |
SF41T-0101200RU |
SF41T-0151200RU |
SF41T-0201200RU |
SF41T-0251200RU |
SF41T-0301200RU |
SF41T-0351200RU |
|
1.1A |
SF41T-0101100RU |
SF41T-0151100RU |
SF41T-0201100RU |
SF41T-0251100RU |
SF41T-0301100RU |
SF41T-0351100RU |
|
1.0A |
SF41T-0101000RU |
SF41T-0151000RU |
SF41T-0201000RU |
SF41T-0251000RU |
SF41T-0301000RU |
SF41T-0351000RU |
|
0.9A |
SF41T-0100900RU |
SF41T-0150900RU |
SF41T-0200900RU |
SF41T-0250900RU |
SF41T-0300900RU |
SF41T-0350900RU |
|
0.8A |
SF41T-0100800RU |
SF41T-0150800RU |
SF41T-0200800RU |
SF41T-0250800RU |
SF41T-0300800RU |
SF41T-0350800RU |
|
0.7A |
SF41T-0100700RU |
SF41T-0150700RU |
SF41T-0200700RU |
SF41T-0250700RU |
SF41T-0300700RU |
SF41T-0350700RU |
|
0.6A |
SF41T-0100600RU |
SF41T-0150600RU |
SF41T-0200600RU |
SF41T-0250600RU |
SF41T-0300600RU |
SF41T-0350600RU |
|
0.5A |
SF41T-0100500RU |
SF41T-0150500RU |
SF41T-0200500RU |
SF41T-0250500RU |
SF41T-0300500RU |
SF41T-0350500RU |
|
0.4A |
SF41T-0100400RU |
SF41T-0150400RU |
SF41T-0200400RU |
SF41T-0250400RU |
SF41T-0300400RU |
SF41T-0350400RU |
|
0.3A |
SF41T-0100300RU |
SF41T-0150300RU |
SF41T-0200300RU |
SF41T-0250300RU |
SF41T-0300300RU |
SF41T-0350300RU |
|
0.2A |
SF41T-0100200RU |
SF41T-0150200RU |
SF41T-0200200RU |
SF41T-0250200RU |
SF41T-0300200RU |
SF41T-0350200RU |
|
0.1A |
SF41T-0100100RU |
SF41T-0150100RU |
SF41T-0200100RU |
SF41T-0250100RU |
SF41T-0300100RU |
SF41T-0350100RU |
|
0.05A |
SF41T-0100050RU |
SF41T-0150050RU |
SF41T-0200050RU |
SF41T-0250050RU |
SF41T-0300050RU |
SF41T-0350050RU |
 |
 |
 |
 |
 |
 |
