LINEAR ADAPTOR
DESKTOP
EI 48 AC TO AC ADAPTOR
INPUT:220V AC 50Hz
|
ELECTRICAL SPECIFICATION |
|||
|---|---|---|---|
|
INPUT |
OUTPUT |
||
|
Input Voltage |
220VAC |
Output Voltage |
3-24V AC |
|
Input Frequency |
50Hz |
Output Tolerance (Load) |
5% |
|
|
|
Output Current |
0.4-3A |
|
|
|
Output Watt |
24.7VA max |
|
GENERAL SPECIFICATION |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
-10 to +30oC |
Operating Humidity |
10 to 90% RH |
|
Storage Temperatures |
-10 to +70oC |
Storage Humidity |
5 to 95% RH |
|
Hi-Pot Test |
Safety |
Compliance With |
|
|
Primary to Core |
3750VAC, one second |
CCC/CB |
IEC 60950 |
|
Primary to Secondary |
3750VAC, one second |
||
OUTPUT SPECIFICATION
|
21V |
22V |
23V |
24V |
|
|
|
|
1.1A |
SF48T-2101100AC |
SF48T-2201100AC |
|
|
|
|
|
1.0A |
SF48T-2101000AC |
SF48T-2201000AC |
SF48T-2301000AC |
SF48T-2401000AC |
|
|
|
0.9A |
SF48T-2100900AC |
SF48T-2200900AC |
SF48T-2300900AC |
SF48T-2400900AC |
|
|
|
0.8A |
SF48T-2100800AC |
SF48T-2200800AC |
SF48T-2300800AC |
SF48T-2400800AC |
|
|
|
0.7A |
SF48T-2100700AC |
SF48T-2200700AC |
SF48T-2300700AC |
SF48T-2400700AC |
|
|
|
0.6A |
SF48T-2100600AC |
SF48T-2200600AC |
SF48T-2300600AC |
SF48T-2400600AC |
|
|
|
0.5A |
SF48T-2100500AC |
SF48T-2200500AC |
SF48T-2300500AC |
SF48T-2400500AC |
|
|
|
0.4A |
SF48T-2100400AC |
SF48T-2200400AC |
SF48T-2300400AC |
SF48T-2400400AC |
|
|
|
15V |
16V |
17V |
18V |
19V |
20V |
|
|
1.6A |
SF48T-1501600AC |
|
|
|
|
|
|
1.5A |
SF48T-1501500AC |
SF48T-1601500AC |
|
|
|
|
|
1.4A |
SF48T-1501400AC |
SF48T-1601400AC |
SF48T-1701400AC |
|
|
|
|
1.3A |
SF48T-1501300AC |
SF48T-1601300AC |
SF48T-1701300AC |
SF48T-1801300AC |
SF48T-1901300AC |
|
|
1.2A |
SF48T-1501200AC |
SF48T-1601200AC |
SF48T-1701200AC |
SF48T-1801200AC |
SF48T-1901200AC |
SF48T-2001200AC |
|
1.1A |
SF48T-1501100AC |
SF48T-1601100AC |
SF48T-1701100AC |
SF48T-1801100AC |
SF48T-1901100AC |
SF48T-2001100AC |
|
1.0A |
SF48T-1501000AC |
SF48T-1601000AC |
SF48T-1701000AC |
SF48T-1801000AC |
SF48T-1901000AC |
SF48T-2001000AC |
|
0.9A |
SF48T-1500900AC |
SF48T-1600900AC |
SF48T-1700900AC |
SF48T-1800900AC |
SF48T-1900900AC |
SF48T-2000900AC |
|
0.8A |
SF48T-1500800AC |
SF48T-1600800AC |
SF48T-1700800AC |
SF48T-1800800AC |
SF48T-1900800AC |
SF48T-2000800AC |
|
0.7A |
SF48T-1500700AC |
SF48T-1600700AC |
SF48T-1700700AC |
SF48T-1800700AC |
SF48T-1900700AC |
SF48T-2000700AC |
|
0.6A |
SF48T-1500600AC |
SF48T-1600600AC |
SF48T-1700600AC |
SF48T-1800600AC |
SF48T-1900600AC |
SF48T-2000600AC |
|
0.5A |
|
|
SF48T-1700500AC |
SF48T-1800500AC |
SF48T-1900500AC |
SF48T-2000500AC |
|
12V |
12.5V |
13V |
13.5V |
14V |
14.5V |
|
|
2.0A |
SF48T-1202000AC |
|
|
|
|
|
|
1.9A |
SF48T-1201900AC |
SF48T-1251900AC |
|
|
|
|
|
1.8A |
SF48T-1201800AC |
SF48T-1251800AC |
SF48T-1301800AC |
|
|
|
|
1.7A |
SF48T-1201700AC |
SF48T-1251700AC |
SF48T-1301700AC |
SF48T-1351700AC |
SF48T-1401700AC |
|
|
1.6A |
SF48T-1201600AC |
SF48T-1251600AC |
SF48T-1301600AC |
SF48T-1351600AC |
SF48T-1401600AC |
SF48T-1451600AC |
|
1.5A |
SF48T-1201500AC |
SF48T-1251500AC |
SF48T-1301500AC |
SF48T-1351500AC |
SF48T-1401500AC |
SF48T-1451500AC |
|
1.4A |
SF48T-1201400AC |
SF48T-1251400AC |
SF48T-1301400AC |
SF48T-1351400AC |
SF48T-1401400AC |
SF48T-1451400AC |
|
1.3A |
SF48T-1201300AC |
SF48T-1251300AC |
SF48T-1301300AC |
SF48T-1351300AC |
SF48T-1401300AC |
SF48T-1451300AC |
|
1.2A |
SF48T-1201200AC |
SF48T-1251200AC |
SF48T-1301200AC |
SF48T-1351200AC |
SF48T-1401200AC |
SF48T-1451200AC |
|
1.1A |
SF48T-1201100AC |
SF48T-1251100AC |
SF48T-1301100AC |
SF48T-1351100AC |
SF48T-1401100AC |
SF48T-1451100AC |
|
1.0A |
SF48T-1201000AC |
SF48T-1251000AC |
SF48T-1301000AC |
SF48T-1351000AC |
SF48T-1401000AC |
SF48T-1451000AC |
|
0.9A |
SF48T-1200900AC |
SF48T-1250900AC |
SF48T-1300900AC |
SF48T-1350900AC |
SF48T-1400900AC |
SF48T-1450900AC |
|
0.8A |
SF48T-1200800AC |
SF48T-1250800AC |
SF48T-1300800AC |
SF48T-1350800AC |
SF48T-1400800AC |
SF48T-1450800AC |
|
0.7A |
|
|
SF48T-1300700AC |
SF48T-1350700AC |
SF48T-1400700AC |
SF48T-1450700AC |
|
0.6A |
|
|
|
|
|
SF48T-1450600AC |
|
9V |
9.5V |
10V |
10.5V |
11V |
11.5V |
|
|
2.5A |
SF48T-0902500AC |
|
|
|
|
|
|
2.4A |
SF48T-0902400AC |
SF48T-0952400AC |
|
|
|
|
|
2.3A |
SF48T-0902300AC |
SF48T-0952300AC |
SF48T-1002300AC |
|
|
|
|
2.2A |
SF48T-0902200AC |
SF48T-0952200AC |
SF48T-1002200AC |
SF48T-1052200AC |
|
|
|
2.1A |
SF48T-0902100AC |
SF48T-0952100AC |
SF48T-1002100AC |
SF48T-1052100AC |
SF48T-1102100AC |
|
|
2.0A |
SF48T-0902000AC |
SF48T-0952000AC |
SF48T-1002000AC |
SF48T-1052000AC |
SF48T-1102000AC |
SF48T-1152000AC |
|
1.9A |
SF48T-0901900AC |
SF48T-0951900AC |
SF48T-1001900AC |
SF48T-1051900AC |
SF48T-1101900AC |
SF48T-1151900AC |
|
1.8A |
SF48T-0901800AC |
SF48T-0951800AC |
SF48T-1001800AC |
SF48T-1051800AC |
SF48T-1101800AC |
SF48T-1151800AC |
|
1.7A |
SF48T-0901700AC |
SF48T-0951700AC |
SF48T-1001700AC |
SF48T-1051700AC |
SF48T-1101700AC |
SF48T-1151700AC |
|
1.6A |
SF48T-0901600AC |
SF48T-0951600AC |
SF48T-1001600AC |
SF48T-1051600AC |
SF48T-1101600AC |
SF48T-1151600AC |
|
1.5A |
SF48T-0901500AC |
SF48T-0951500AC |
SF48T-1001500AC |
SF48T-1051500AC |
SF48T-1101500AC |
SF48T-1151500AC |
|
1.4A |
SF48T-0901400AC |
SF48T-0951400AC |
SF48T-1001400AC |
SF48T-1051400AC |
SF48T-1101400AC |
SF48T-1151400AC |
|
1.3A |
SF48T-0901300AC |
SF48T-0951300AC |
SF48T-1001300AC |
SF48T-1051300AC |
SF48T-1101300AC |
SF48T-1151300AC |
|
1.2A |
SF48T-0901200AC |
SF48T-0951200AC |
SF48T-1001200AC |
SF48T-1051200AC |
SF48T-1101200AC |
SF48T-1151200AC |
|
1.1A |
SF48T-0901100AC |
SF48T-0951100AC |
SF48T-1001100AC |
SF48T-1051100AC |
SF48T-1101100AC |
SF48T-1151100AC |
|
1.0A |
|
SF48T-0951000AC |
SF48T-1001000AC |
SF48T-1051000AC |
SF48T-1101000AC |
SF48T-1151000AC |
|
0.9A |
|
|
SF48T-1000900AC |
SF48T-1050900AC |
SF48T-1100900AC |
SF48T-1150900AC |
|
0.8A |
|
|
|
|
|
SF48T-1150800AC |
|
6V |
6.5V |
7V |
7.5V |
8V |
8.5V |
|
|
3.0A |
SF48T-0603000AC |
SF48T-0653000AC |
|
|
|
|
|
2.9A |
SF48T-0602900AC |
SF48T-0652900AC |
SF48T-0702900AC |
|
|
|
|
2.8A |
SF48T-0602800AC |
SF48T-0652800AC |
SF48T-0702800AC |
SF48T-0752800AC |
|
|
|
2.7A |
SF48T-0602700AC |
SF48T-0652700AC |
SF48T-0702700AC |
SF48T-0752700AC |
SF48T-0802700AC |
|
|
2.6A |
SF48T-0602600AC |
SF48T-0652600AC |
SF48T-0702600AC |
SF48T-0752600AC |
SF48T-0802600AC |
SF48T-0852600AC |
|
2.5A |
SF48T-0602500AC |
SF48T-0652500AC |
SF48T-0702500AC |
SF48T-0752500AC |
SF48T-0802500AC |
SF48T-0852500AC |
|
2.4A |
SF48T-0602400AC |
SF48T-0652400AC |
SF48T-0702400AC |
SF48T-0752400AC |
SF48T-0802400AC |
SF48T-0852400AC |
|
2.3A |
SF48T-0602300AC |
SF48T-0652300AC |
SF48T-0702300AC |
SF48T-0752300AC |
SF48T-0802300AC |
SF48T-0852300AC |
|
2.2A |
SF48T-0602200AC |
SF48T-0652200AC |
SF48T-0702200AC |
SF48T-0752200AC |
SF48T-0802200AC |
SF48T-0852200AC |
|
2.1A |
SF48T-0602100AC |
SF48T-0652100AC |
SF48T-0702100AC |
SF48T-0752100AC |
SF48T-0802100AC |
SF48T-0852100AC |
|
2.0A |
SF48T-0602000AC |
SF48T-0652000AC |
SF48T-0702000AC |
SF48T-0752000AC |
SF48T-0802000AC |
SF48T-0852000AC |
|
1.9A |
SF48T-0601900AC |
SF48T-0651900AC |
SF48T-0701900AC |
SF48T-0751900AC |
SF48T-0801900AC |
SF48T-0851900AC |
|
1.8A |
SF48T-0601800AC |
SF48T-0651800AC |
SF48T-0701800AC |
SF48T-0751800AC |
SF48T-0801800AC |
SF48T-0851800AC |
|
1.7A |
SF48T-0601700AC |
SF48T-0651700AC |
SF48T-0701700AC |
SF48T-0751700AC |
SF48T-0801700AC |
SF48T-0851700AC |
|
1.6A |
SF48T-0601600AC |
SF48T-0651600AC |
SF48T-0701600AC |
SF48T-0751600AC |
SF48T-0801600AC |
SF48T-0851600AC |
|
1.5A |
SF48T-0601500AC |
SF48T-0651500AC |
SF48T-0701500AC |
SF48T-0751500AC |
SF48T-0801500AC |
SF48T-0851500AC |
|
1.4A |
SF48T-0601400AC |
SF48T-0651400AC |
SF48T-0701400AC |
SF48T-0751400AC |
SF48T-0801400AC |
SF48T-0851400AC |
|
1.3A |
SF48T-0601300AC |
SF48T-0651300AC |
SF48T-0701300AC |
SF48T-0751300AC |
SF48T-0801300AC |
SF48T-0851300AC |
|
1.2A |
SF48T-0601200AC |
SF48T-0651200AC |
SF48T-0701200AC |
SF48T-0751200AC |
SF48T-0801200AC |
SF48T-0851200AC |
|
1.1A |
|
|
|
|
SF48T-0801100AC |
SF48T-0851100AC |
|
3V |
3.5V |
4V |
4.5V |
5V |
5.5V |
|
|
3.0A |
SF48T-0303000AC |
SF48T-0353000AC |
SF48T-0403000AC |
SF48T-0453000AC |
SF48T-0503000AC |
SF48T-0553000AC |
|
2.9A |
SF48T-0302900AC |
SF48T-0352900AC |
SF48T-0402900AC |
SF48T-0452900AC |
SF48T-0502900AC |
SF48T-0552900AC |
|
2.8A |
SF48T-0302800AC |
SF48T-0352800AC |
SF48T-0402800AC |
SF48T-0452800AC |
SF48T-0502800AC |
SF48T-0552800AC |
|
2.7A |
SF48T-0302700AC |
SF48T-0352700AC |
SF48T-0402700AC |
SF48T-0452700AC |
SF48T-0502700AC |
SF48T-0552700AC |
|
2.6A |
SF48T-0302600AC |
SF48T-0352600AC |
SF48T-0402600AC |
SF48T-0452600AC |
SF48T-0502600AC |
SF48T-0552600AC |
|
2.5A |
SF48T-0302500AC |
SF48T-0352500AC |
SF48T-0402500AC |
SF48T-0452500AC |
SF48T-0502500AC |
SF48T-0552500AC |
|
2.4A |
SF48T-0302400AC |
SF48T-0352400AC |
SF48T-0402400AC |
SF48T-0452400AC |
SF48T-0502400AC |
SF48T-0552400AC |
|
2.3A |
SF48T-0302300AC |
SF48T-0352300AC |
SF48T-0402300AC |
SF48T-0452300AC |
SF48T-0502300AC |
SF48T-0552300AC |
|
2.2A |
SF48T-0302200AC |
SF48T-0352200AC |
SF48T-0402200AC |
SF48T-0452200AC |
SF48T-0502200AC |
SF48T-0552200AC |
|
2.1A |
SF48T-0302100AC |
SF48T-0352100AC |
SF48T-0402100AC |
SF48T-0452100AC |
SF48T-0502100AC |
SF48T-0552100AC |
|
2.0A |
SF48T-0302000AC |
SF48T-0352000AC |
SF48T-0402000AC |
SF48T-0452000AC |
SF48T-0502000AC |
SF48T-0552000AC |
|
1.9A |
SF48T-0301900AC |
SF48T-0351900AC |
SF48T-0401900AC |
SF48T-0451900AC |
SF48T-0501900AC |
SF48T-0551900AC |
|
1.8A |
SF48T-0301800AC |
SF48T-0351800AC |
SF48T-0401800AC |
SF48T-0451800AC |
SF48T-0501800AC |
SF48T-0551800AC |
|
1.7A |
SF48T-0301700AC |
SF48T-0351700AC |
SF48T-0401700AC |
SF48T-0451700AC |
SF48T-0501700AC |
SF48T-0551700AC |
|
1.6A |
SF48T-0301600AC |
SF48T-0351600AC |
SF48T-0401600AC |
SF48T-0451600AC |
SF48T-0501600AC |
SF48T-0551600AC |
|
1.5A |
|
SF48T-0351500AC |
SF48T-0401500AC |
SF48T-0451500AC |
SF48T-0501500AC |
SF48T-0551500AC |
|
1.4A |
|
|
|
SF48T-0451400AC |
SF48T-0501400AC |
SF48T-0551400AC |
|
1.3A |
|
|
|
SF48T-0451300AC |
SF48T-0501300AC |
SF48T-0551300AC |
|
3-5.5V |
6-8.5V |
9-11.5V |
12-14.5V |
15-20V |
21-24V |
 |
 |
 |
 |
 |
 |
