LINEAR ADAPTOR
DESKTOP
EI 66 AC TO AC ADAPTOR
INPUT:220V AC 50Hz
|
ELECTRICAL SPECIFICATION |
|||
|---|---|---|---|
|
INPUT |
OUTPUT |
||
|
Input Voltage |
220VAC |
Output Voltage |
3-27V AC |
|
Input Frequency |
50Hz |
Output Tolerance (Load) |
5% |
|
|
|
Output Current |
1.1-4A |
|
|
|
Output Watt |
54VA max |
|
GENERAL SPECIFICATION |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
-10 to +30oC |
Operating Humidity |
10 to 90% RH |
|
Storage Temperatures |
-10 to +70oC |
Storage Humidity |
5 to 95% RH |
|
Hi-Pot Test |
Safety |
Compliance With |
|
|
Primary to Core |
3750VAC, one second |
CCC |
IEC 60950 |
|
Primary to Secondary |
3750VAC, one second |
||
OUTPUT SPECIFICATION
|
27V |
|
|
|
|
|
|
|
1.9A |
SF66T-2701900AC |
|
|
|
|
|
|
1.8A |
SF66T-2701800AC |
|
|
|
|
|
|
1.7A |
SF66T-2701700AC |
|
|
|
|
|
|
1.6A |
SF66T-2701600AC |
|
|
|
|
|
|
1.5A |
SF66T-2701500AC |
|
|
|
|
|
|
1.4A |
SF66T-2701400AC |
|
|
|
|
|
|
1.3A |
SF66T-2701300AC |
|
|
|
|
|
|
1.2A |
SF66T-2701200AC |
|
|
|
|
|
|
1.1A |
SF66T-2701100AC |
|
|
|
|
|
|
21V |
22V |
23V |
24V |
25V |
26V |
|
|
2.3A |
SF66T-2102300AC |
|
|
|
|
|
|
2.2A |
SF66T-2102200AC |
SF66T-2202200AC |
|
|
|
|
|
2.1A |
SF66T-2102100AC |
SF66T-2202100AC |
SF66T-2302100AC |
|
|
|
|
2.0A |
SF66T-2102000AC |
SF66T-2202000AC |
SF66T-2302000AC |
SF66T-2402000AC |
SF66T-2502000AC |
|
|
1.9A |
SF66T-2101900AC |
SF66T-2201900AC |
SF66T-2301900AC |
SF66T-2401900AC |
SF66T-2501900AC |
SF66T-2601900AC |
|
1.8A |
SF66T-2101800AC |
SF66T-2201800AC |
SF66T-2301800AC |
SF66T-2401800AC |
SF66T-2501800AC |
SF66T-2601800AC |
|
1.7A |
SF66T-2101700AC |
SF66T-2201700AC |
SF66T-2301700AC |
SF66T-2401700AC |
SF66T-2501700AC |
SF66T-2601700AC |
|
1.6A |
SF66T-2101600AC |
SF66T-2201600AC |
SF66T-2301600AC |
SF66T-2401600AC |
SF66T-2501600AC |
SF66T-2601600AC |
|
1.5A |
SF66T-2101500AC |
SF66T-2201500AC |
SF66T-2301500AC |
SF66T-2401500AC |
SF66T-2501500AC |
SF66T-2601500AC |
|
1.4A |
|
SF66T-2201400AC |
SF66T-2301400AC |
SF66T-2401400AC |
SF66T-2501400AC |
SF66T-2601400AC |
|
1.3A |
|
|
SF66T-2301300AC |
SF66T-2401300AC |
SF66T-2501300AC |
SF66T-2601300AC |
|
1.2A |
|
|
|
SF66T-2401200AC |
SF66T-2501200AC |
SF66T-2601200AC |
|
1.1A |
|
|
|
|
|
SF66T-2601100AC |
|
15V |
16V |
17V |
18V |
19V |
20V |
|
|
3.3A |
SF66T-1503300AC |
|
|
|
|
|
|
3.2A |
SF66T-1503200AC |
|
|
|
|
|
|
3.1A |
SF66T-1503100AC |
SF66T-1603100AC |
|
|
|
|
|
3.0A |
SF66T-1503000AC |
SF66T-1603000AC |
|
|
|
|
|
2.9A |
SF66T-1502900AC |
SF66T-1602900AC |
SF66T-1702900AC |
|
|
|
|
2.8A |
SF66T-1502800AC |
SF66T-1602800AC |
SF66T-1702800AC |
|
|
|
|
2.7A |
SF66T-1502700AC |
SF66T-1602700AC |
SF66T-1702700AC |
SF66T-1802700AC |
|
|
|
2.6A |
SF66T-1502600AC |
SF66T-1602600AC |
SF66T-1702600AC |
SF66T-1802600AC |
SF66T-1902600AC |
|
|
2.5A |
SF66T-1502500AC |
SF66T-1602500AC |
SF66T-1702500AC |
SF66T-1802500AC |
SF66T-1902500AC |
SF66T-2002500AC |
|
2.4A |
SF66T-1502400AC |
SF66T-1602400AC |
SF66T-1702400AC |
SF66T-1802400AC |
SF66T-1902400AC |
SF66T-2002400AC |
|
2.3A |
SF66T-1502300AC |
SF66T-1602300AC |
SF66T-1702300AC |
SF66T-1802300AC |
SF66T-1902300AC |
SF66T-2002300AC |
|
2.2A |
SF66T-1502200AC |
SF66T-1602200AC |
SF66T-1702200AC |
SF66T-1802200AC |
SF66T-1902200AC |
SF66T-2002200AC |
|
2.1A |
SF66T-1502100AC |
SF66T-1602100AC |
SF66T-1702100AC |
SF66T-1802100AC |
SF66T-1902100AC |
SF66T-2002100AC |
|
2.0A |
SF66T-1502000AC |
SF66T-1602000AC |
SF66T-1702000AC |
SF66T-1802000AC |
SF66T-1902000AC |
SF66T-2002000AC |
|
1.9A |
SF66T-1501900AC |
SF66T-1601900AC |
SF66T-1701900AC |
SF66T-1801900AC |
SF66T-1901900AC |
SF66T-2001900AC |
|
1.8A |
|
|
SF66T-1701800AC |
SF66T-1801800AC |
SF66T-1901800AC |
SF66T-2001800AC |
|
1.7A |
|
|
|
SF66T-1801700AC |
SF66T-1901700AC |
SF66T-2001700AC |
|
1.6A |
|
|
|
|
SF66T-1901600AC |
SF66T-2001600AC |
|
12V |
12.5V |
13V |
13.5V |
14V |
14.5V |
|
|
4.0A |
SF66T-1204000AC |
|
|
|
|
|
|
3.9A |
SF66T-1203900AC |
SF66T-1253900AC |
|
|
|
|
|
3.8A |
SF66T-1203800AC |
SF66T-1253800AC |
SF66T-1303800AC |
|
|
|
|
3.7A |
SF66T-1203700AC |
SF66T-1253700AC |
SF66T-1303700AC |
SF66T-1353700AC |
|
|
|
3.6A |
SF66T-1203600AC |
SF66T-1253600AC |
SF66T-1303600AC |
SF66T-1353600AC |
|
|
|
3.5A |
SF66T-1203500AC |
SF66T-1253500AC |
SF66T-1303500AC |
SF66T-1353500AC |
SF66T-1403500AC |
|
|
3.4A |
SF66T-1203400AC |
SF66T-1253400AC |
SF66T-1303400AC |
SF66T-1353400AC |
SF66T-1403400AC |
SF66T-1453400AC |
|
3.3A |
SF66T-1203300AC |
SF66T-1253300AC |
SF66T-1303300AC |
SF66T-1353300AC |
SF66T-1403300AC |
SF66T-1453300AC |
|
3.2A |
SF66T-1203200AC |
SF66T-1253200AC |
SF66T-1303200AC |
SF66T-1353200AC |
SF66T-1403200AC |
SF66T-1453200AC |
|
3.1A |
SF66T-1203100AC |
SF66T-1253100AC |
SF66T-1303100AC |
SF66T-1353100AC |
SF66T-1403100AC |
SF66T-1453100AC |
|
3.0A |
SF66T-1203000AC |
SF66T-1253000AC |
SF66T-1303000AC |
SF66T-1353000AC |
SF66T-1403000AC |
SF66T-1453000AC |
|
2.9A |
SF66T-1202900AC |
SF66T-1252900AC |
SF66T-1302900AC |
SF66T-1352900AC |
SF66T-1402900AC |
SF66T-1452900AC |
|
2.8A |
SF66T-1202800AC |
SF66T-1252800AC |
SF66T-1302800AC |
SF66T-1352800AC |
SF66T-1402800AC |
SF66T-1452800AC |
|
2.7A |
SF66T-1202700AC |
SF66T-1252700AC |
SF66T-1302700AC |
SF66T-1352700AC |
SF66T-1402700AC |
SF66T-1452700AC |
|
2.6A |
SF66T-1202600AC |
SF66T-1252600AC |
SF66T-1302600AC |
SF66T-1352600AC |
SF66T-1402600AC |
SF66T-1452600AC |
|
2.5A |
SF66T-1202500AC |
SF66T-1252500AC |
SF66T-1302500AC |
SF66T-1352500AC |
SF66T-1402500AC |
SF66T-1452500AC |
|
2.4A |
SF66T-1202400AC |
SF66T-1252400AC |
SF66T-1302400AC |
SF66T-1352400AC |
SF66T-1402400AC |
SF66T-1452400AC |
|
2.3A |
SF66T-1202300AC |
SF66T-1252300AC |
SF66T-1302300AC |
SF66T-1352300AC |
SF66T-1402300AC |
SF66T-1452300AC |
|
2.2A |
|
SF66T-1252200AC |
SF66T-1302200AC |
SF66T-1352200AC |
SF66T-1402200AC |
SF66T-1452200AC |
|
2.1A |
|
|
SF66T-1302100AC |
SF66T-1352100AC |
SF66T-1402100AC |
SF66T-1452100AC |
|
2.0A |
|
|
|
|
SF66T-1402000AC |
SF66T-1452000AC |
|
9V |
9.5V |
10V |
10.5V |
11V |
11.5V |
|
|
4.0A |
SF66T-0904000AC |
SF66T-0954000AC |
SF66T-1004000AC |
SF66T-1054000AC |
SF66T-1104000AC |
SF66T-1154000AC |
|
3.9A |
SF66T-0903900AC |
SF66T-0953900AC |
SF66T-1003900AC |
SF66T-1053900AC |
SF66T-1103900AC |
SF66T-1153900AC |
|
3.8A |
SF66T-0903800AC |
SF66T-0953800AC |
SF66T-1003800AC |
SF66T-1053800AC |
SF66T-1103800AC |
SF66T-1153800AC |
|
3.7A |
SF66T-0903700AC |
SF66T-0953700AC |
SF66T-1003700AC |
SF66T-1053700AC |
SF66T-1103700AC |
SF66T-1153700AC |
|
3.6A |
SF66T-0903600AC |
SF66T-0953600AC |
SF66T-1003600AC |
SF66T-1053600AC |
SF66T-1103600AC |
SF66T-1153600AC |
|
3.5A |
SF66T-0903500AC |
SF66T-0953500AC |
SF66T-1003500AC |
SF66T-1053500AC |
SF66T-1103500AC |
SF66T-1153500AC |
|
3.4A |
SF66T-0903400AC |
SF66T-0953400AC |
SF66T-1003400AC |
SF66T-1053400AC |
SF66T-1103400AC |
SF66T-1153400AC |
|
3.3A |
SF66T-0903300AC |
SF66T-0953300AC |
SF66T-1003300AC |
SF66T-1053300AC |
SF66T-1103300AC |
SF66T-1153300AC |
|
3.2A |
SF66T-0903200AC |
SF66T-0953200AC |
SF66T-1003200AC |
SF66T-1053200AC |
SF66T-1103200AC |
SF66T-1153200AC |
|
3.1A |
SF66T-0903100AC |
SF66T-0953100AC |
SF66T-1003100AC |
SF66T-1053100AC |
SF66T-1103100AC |
SF66T-1153100AC |
|
3.0A |
SF66T-0903000AC |
SF66T-0953000AC |
SF66T-1003000AC |
SF66T-1053000AC |
SF66T-1103000AC |
SF66T-1153000AC |
|
2.9A |
SF66T-0902900AC |
SF66T-0952900AC |
SF66T-1002900AC |
SF66T-1052900AC |
SF66T-1102900AC |
SF66T-1152900AC |
|
2.8A |
SF66T-0902800AC |
SF66T-0952800AC |
SF66T-1002800AC |
SF66T-1052800AC |
SF66T-1102800AC |
SF66T-1152800AC |
|
2.7A |
SF66T-0902700AC |
SF66T-0952700AC |
SF66T-1002700AC |
SF66T-1052700AC |
SF66T-1102700AC |
SF66T-1152700AC |
|
2.6A |
SF66T-0902600AC |
SF66T-0952600AC |
SF66T-1002600AC |
SF66T-1052600AC |
SF66T-1102600AC |
SF66T-1152600AC |
|
2.5A |
SF66T-0902500AC |
SF66T-0952500AC |
SF66T-1002500AC |
SF66T-1052500AC |
SF66T-1102500AC |
SF66T-1152500AC |
|
2.4A |
SF66T-0902400AC |
SF66T-0952400AC |
SF66T-1002400AC |
SF66T-1052400AC |
SF66T-1102400AC |
SF66T-1152400AC |
|
2.3A |
SF66T-0902300AC |
SF66T-0952300AC |
SF66T-1002300AC |
SF66T-1052300AC |
SF66T-1102300AC |
SF66T-1152300AC |
|
6V |
6.5V |
7V |
7.5V |
8V |
8.5V |
|
|
4.0A |
SF66T-0604000AC |
SF66T-0654000AC |
SF66T-0704000AC |
SF66T-0754000AC |
SF66T-0804000AC |
SF66T-0854000AC |
|
3.9A |
SF66T-0603900AC |
SF66T-0653900AC |
SF66T-0703900AC |
SF66T-0753900AC |
SF66T-0803900AC |
SF66T-0853900AC |
|
3.8A |
SF66T-0603800AC |
SF66T-0653800AC |
SF66T-0703800AC |
SF66T-0753800AC |
SF66T-0803800AC |
SF66T-0853800AC |
|
3.7A |
SF66T-0603700AC |
SF66T-0653700AC |
SF66T-0703700AC |
SF66T-0753700AC |
SF66T-0803700AC |
SF66T-0853700AC |
|
3.6A |
SF66T-0603600AC |
SF66T-0653600AC |
SF66T-0703600AC |
SF66T-0753600AC |
SF66T-0803600AC |
SF66T-0853600AC |
|
3.5A |
SF66T-0603500AC |
SF66T-0653500AC |
SF66T-0703500AC |
SF66T-0753500AC |
SF66T-0803500AC |
SF66T-0853500AC |
|
3.4A |
SF66T-0603400AC |
SF66T-0653400AC |
SF66T-0703400AC |
SF66T-0753400AC |
SF66T-0803400AC |
SF66T-0853400AC |
|
3.3A |
SF66T-0603300AC |
SF66T-0653300AC |
SF66T-0703300AC |
SF66T-0753300AC |
SF66T-0803300AC |
SF66T-0853300AC |
|
3.2A |
SF66T-0603200AC |
SF66T-0653200AC |
SF66T-0703200AC |
SF66T-0753200AC |
SF66T-0803200AC |
SF66T-0853200AC |
|
3.1A |
SF66T-0603100AC |
SF66T-0653100AC |
SF66T-0703100AC |
SF66T-0753100AC |
SF66T-0803100AC |
SF66T-0853100AC |
|
3.0A |
SF66T-0603000AC |
SF66T-0653000AC |
SF66T-0703000AC |
SF66T-0753000AC |
SF66T-0803000AC |
SF66T-0853000AC |
|
2.9A |
SF66T-0602900AC |
SF66T-0652900AC |
SF66T-0702900AC |
SF66T-0752900AC |
SF66T-0802900AC |
SF66T-0852900AC |
|
2.8A |
SF66T-0602800AC |
SF66T-0652800AC |
SF66T-0702800AC |
SF66T-0752800AC |
SF66T-0802800AC |
SF66T-0852800AC |
|
2.7A |
SF66T-0602700AC |
SF66T-0652700AC |
SF66T-0702700AC |
SF66T-0752700AC |
SF66T-0802700AC |
SF66T-0852700AC |
|
2.6A |
SF66T-0602600AC |
SF66T-0652600AC |
SF66T-0702600AC |
SF66T-0752600AC |
SF66T-0802600AC |
SF66T-0852600AC |
|
2.5A |
SF66T-0602500AC |
SF66T-0652500AC |
SF66T-0702500AC |
SF66T-0752500AC |
SF66T-0802500AC |
SF66T-0852500AC |
|
2.4A |
SF66T-0602400AC |
SF66T-0652400AC |
SF66T-0702400AC |
SF66T-0752400AC |
SF66T-0802400AC |
SF66T-0852400AC |
|
2.3A |
SF66T-0602300AC |
SF66T-0652300AC |
SF66T-0702300AC |
SF66T-0752300AC |
SF66T-0802300AC |
SF66T-0852300AC |
|
3V |
3.5V |
4V |
4.5V |
5V |
5.5V |
|
|
4.0A |
SF66T-0304000AC |
SF66T-0354000AC |
SF66T-0404000AC |
SF66T-0454000AC |
SF66T-0504000AC |
SF66T-0554000AC |
|
3.9A |
SF66T-0303900AC |
SF66T-0353900AC |
SF66T-0403900AC |
SF66T-0453900AC |
SF66T-0503900AC |
SF66T-0553900AC |
|
3.8A |
SF66T-0303800AC |
SF66T-0353800AC |
SF66T-0403800AC |
SF66T-0453800AC |
SF66T-0503800AC |
SF66T-0553800AC |
|
3.7A |
SF66T-0303700AC |
SF66T-0353700AC |
SF66T-0403700AC |
SF66T-0453700AC |
SF66T-0503700AC |
SF66T-0553700AC |
|
3.6A |
SF66T-0303600AC |
SF66T-0353600AC |
SF66T-0403600AC |
SF66T-0453600AC |
SF66T-0503600AC |
SF66T-0553600AC |
|
3.5A |
SF66T-0303500AC |
SF66T-0353500AC |
SF66T-0403500AC |
SF66T-0453500AC |
SF66T-0503500AC |
SF66T-0553500AC |
|
3.4A |
SF66T-0303400AC |
SF66T-0353400AC |
SF66T-0403400AC |
SF66T-0453400AC |
SF66T-0503400AC |
SF66T-0553400AC |
|
3.3A |
SF66T-0303300AC |
SF66T-0353300AC |
SF66T-0403300AC |
SF66T-0453300AC |
SF66T-0503300AC |
SF66T-0553300AC |
|
3.2A |
SF66T-0303200AC |
SF66T-0353200AC |
SF66T-0403200AC |
SF66T-0453200AC |
SF66T-0503200AC |
SF66T-0553200AC |
|
3.1A |
SF66T-0303100AC |
SF66T-0353100AC |
SF66T-0403100AC |
SF66T-0453100AC |
SF66T-0503100AC |
SF66T-0553100AC |
|
3.0A |
SF66T-0303000AC |
SF66T-0353000AC |
SF66T-0403000AC |
SF66T-0453000AC |
SF66T-0503000AC |
SF66T-0553000AC |
|
2.9A |
SF66T-0302900AC |
SF66T-0352900AC |
SF66T-0402900AC |
SF66T-0452900AC |
SF66T-0502900AC |
SF66T-0552900AC |
|
2.8A |
SF66T-0302800AC |
SF66T-0352800AC |
SF66T-0402800AC |
SF66T-0452800AC |
SF66T-0502800AC |
SF66T-0552800AC |
|
2.7A |
SF66T-0302700AC |
SF66T-0352700AC |
SF66T-0402700AC |
SF66T-0452700AC |
SF66T-0502700AC |
SF66T-0552700AC |
|
2.6A |
SF66T-0302600AC |
SF66T-0352600AC |
SF66T-0402600AC |
SF66T-0452600AC |
SF66T-0502600AC |
SF66T-0552600AC |
|
2.5A |
SF66T-0302500AC |
SF66T-0352500AC |
SF66T-0402500AC |
SF66T-0452500AC |
SF66T-0502500AC |
SF66T-0552500AC |
|
2.4A |
SF66T-0302400AC |
SF66T-0352400AC |
SF66T-0402400AC |
SF66T-0452400AC |
SF66T-0502400AC |
SF66T-0552400AC |
|
2.3A |
SF66T-0302300AC |
SF66T-0352300AC |
SF66T-0402300AC |
SF66T-0452300AC |
SF66T-0502300AC |
SF66T-0552300AC |
|
3-5.5V |
6-8.5V |
9-11.5V |
12-14.5V |
15-20V |
21-26V |
27V |
 |
 |
 |
 |
 |
 |
