GENERAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
0 to +40oC |
Operating Humidity |
20 to 90% RH |
|
Storage Temperatures |
-20 to +85oC |
Storage Humidity |
20 to 90% RH |
|
Hi-Pot Test |
MTBF |
||
|
Hi-Pot |
4000V AC |
MTBF |
370,000Hours at 25oC |
|
EMISSSION |
SAFETY |
||
|
EMI/EMC |
FCC |
Safety Approvals |
UL/CUL/GS/CE/CB |
|
Safety Compliant |
EN 60601/IEC 601/UL 2601 Class I for medical applications |
||
|
ELECTRICAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Input |
Output |
||
|
Input Voltage Range |
90-264V AC |
Output Voltage |
3.3 - 30V DC |
|
Input Frequency |
47-63Hz |
Output Current |
4A(22VA max) |
|
Input Current |
0.38A(max) |
Output Tolerance |
5% |
|
|
|
Ripple & Noise |
1%p-p max |
|
|
|
Efficiency |
80% |
OUTPUT SPECIFICATIONS
SERIES NO. : IEC22
SWITCHING ADAPTOR
DESKTOP-INLET SOCKET
22 SERIES
|
PART NO. |
OUTPUT |
|
|
VOLT |
CURRENT (max) |
|
|
IEC22-0334000 |
3.3V |
4.00A |
|
IEC22-0504000 |
5.0V |
4.00A |
|
IEC22-0753000 |
7.5V |
3.00A |
|
IEC22-0902500 |
9.0V |
2.50A |
|
IEC22-1202000 |
12.0V |
2.00A |
|
IEC22-1501600 |
15.0V |
1.60A |
|
IEC22-2101150 |
21.0V |
1.15A |
|
IEC22-2401000 |
24.0V |
1.00A |
|
IEC22-3000800 |
30.0V |
0.80A |
 |
 |
 |
 |
 |
 |
