ELECTRICAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Input |
Output |
||
|
Input Voltage Range |
90-264V AC |
Output Voltage |
7.5 - 29V DC |
|
Input Frequency |
47-63Hz |
Output Current |
4.16A(50VA max) |
|
Input Current |
1.0A(max) |
Output Tolerance |
5% |
|
|
|
Ripple & Noise |
100mV ~ 150mV |
|
|
|
Efficiency |
>80% |
OUTPUT SPECIFICATIONS
SERIES NO. : IEC50
SWITCHING ADAPTOR
DESKTOP-INLET SOCKET
50 SERIES
PART NO. |
OUTPUT |
|
VOLT |
CURRENT |
|
IEC50-0754000 |
7.5V |
4.00A |
IEC50-0803800 |
8.0V |
3.80A |
IEC50-0904000 |
9.0V |
4.00A |
IEC50-0903700 |
9.0V |
3.70A |
IEC50-0903400 |
9.0V |
3.40A |
IEC50-0954000 |
9.5V |
4.00A |
IEC50-1003600 |
10.0V |
3.60A |
IEC50-1003200 |
10.0V |
3.20A |
IEC50-1054000 |
10.5V |
4.00A |
IEC50-1053200 |
10.5V |
3.20A |
IEC50-1104000 |
11.0V |
4.00A |
IEC50-1103600 |
11.0V |
3.60A |
IEC50-1154000 |
11.5V |
4.00A |
IEC50-1153000 |
11.5V |
3.00A |
IEC50-1204160 |
12.0V |
4.16A |
IEC50-1204000 |
12.0V |
4.00A |
IEC50-1203700 |
12.0V |
3.70A |
IEC50-1203400 |
12.0V |
3.40A |
IEC50-1203000 |
12.0V |
3.00A |
IEC50-1202800 |
12.0V |
2.80A |
IEC50-1202500 |
12.0V |
2.50A |
IEC50-1253600 |
12.5V |
3.60A |
IEC50-1252800 |
12.5V |
2.80A |
IEC50-1303600 |
13.0V |
3.60A |
IEC50-1302500 |
13.0V |
2.50A |
IEC50-1353300 |
13.5V |
3.30A |
IEC50-1352800 |
13.5V |
2.80A |
IEC50-1352500 |
13.5V |
2.50A |
IEC50-1403200 |
14.0V |
3.20A |
IEC50-1402600 |
14.0V |
2.60A |
IEC50-1453000 |
14.5V |
3.00A |
IEC50-1452600 |
14.5V |
2.60A |
IEC50-1503200 |
15.0V |
3.20A |
IEC50-1502800 |
15.0V |
2.80A |
IEC50-1502600 |
15.0V |
2.60A |
IEC50-1502000 |
15.0V |
2.00A |
IEC50-1553000 |
15.5V |
3.00A |
IEC50-1552600 |
15.5V |
2.60A |
IEC50-1602800 |
16.0V |
2.80A |
IEC50-1652800 |
16.5V |
2.80A |
IEC50-1652400 |
16.5V |
2.40A |
IEC50-1702600 |
17.0V |
2.60A |
IEC50-1752600 |
17.5V |
2.60A |
IEC50-1752000
|
17.5V |
2.00A |
PART NO. |
OUTPUT |
|
VOLT |
CURRENT |
|
IEC50-1802600 |
18.0V |
2.60A |
IEC50-1802300 |
18.0V |
2.30A |
IEC50-1802000 |
18.0V |
2.00A |
IEC50-1801800 |
18.0V |
1.80A |
IEC50-1852400 |
18.5V |
2.40A |
IEC50-1902400 |
19.0V |
2.40A |
IEC50-1901800 |
19.0V |
1.80A |
IEC50-1952200 |
19.5V |
2.20A |
IEC50-1951600 |
19.5V |
1.60A |
IEC50-2002200 |
20.0V |
2.20A |
IEC50-2052200 |
20.5V |
2.20A |
IEC50-2051800 |
20.5V |
1.80A |
IEC50-2102000 |
21.0V |
2.00A |
IEC50-2101500 |
21.0V |
1.50A |
IEC50-2152000 |
21.5V |
2.00A |
IEC50-2151500 |
21.5V |
1.50A |
IEC50-2202000 |
22.0V |
2.00A |
IEC50-2201500 |
22.0V |
1.50A |
IEC50-2252000 |
22.5V |
2.00A |
IEC50-2251500 |
22.5V |
1.50A |
IEC50-2302000 |
23.0V |
2.00A |
IEC50-2301500 |
23.0V |
1.50A |
IEC50-2351900 |
23.5V |
1.90A |
IEC50-2351500 |
23.5V |
1.50A |
IEC50-2402000 |
24.0V |
2.00A |
IEC50-2401800 |
24.0V |
1.80A |
IEC50-2401500 |
24.0V |
1.50A |
IEC50-2401250 |
24.0V |
1.25A |
IEC50-2451800 |
24.5V |
1.80A |
IEC50-2501800 |
25.0V |
1.80A |
IEC50-2501500 |
25.0V |
1.50A |
IEC50-2551800 |
25.5V |
1.80A |
IEC50-2601800 |
26.0V |
1.80A |
IEC50-2601300 |
26.0V |
1.30A |
IEC50-2651700 |
26.5V |
1.70A |
IEC50-2701300 |
27.0V |
1.30A |
IEC50-2751600 |
27.5V |
1.60A |
IEC50-2801600 |
28.0V |
1.60A |
IEC50-2801200 |
28.0V |
1.20A |
IEC50-2851600 |
28.5V |
1.60A |
IEC50-2901100 |
29.0V |
1.10A |
IEC50-2901650 |
29.0V |
1.65A |
|
GENERAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
0 to +40oC |
Operating Humidity |
15 to 95% RH |
|
Storage Temperatures |
-20 to +70oC |
Storage Humidity |
5 to 95% RH |
|
Hi-Pot Test |
MTBF |
||
|
Hi-Pot |
3000V AC/10mA/3S |
MTBF |
30,000Hours at 25oC |
|
EMISSION |
SAFETY |
||
|
EMI/EMC |
EMC/FCC |
Safety Approvals |
UL/CUL/CE/CB |
|
GREEN POWER |
Safety Compliant |
UL 60950/EN 60950 |
|
|
CEC/ErP |
|||
 |
 |
 |
 |
 |
 |
