GENERAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
0 to +40oC |
Operating Humidity |
20 to 90% RH |
|
Storage Temperatures |
-20 to +85oC |
Storage Humidity |
20 to 90% RH |
|
Hi-Pot Test |
MTBF |
||
|
Hi-Pot |
4000V AC |
MTBF |
430,000Hours at 25oC |
|
EMISSSION |
SAFETY |
||
|
EMI/EMC |
FCC |
Safety Approvals |
UL/CUL/GS/CE/CB |
|
Safety Compliant |
IEC 60601/EN 60601/UL 2601,Class I for C14, or Class II for C8 type |
||
|
ELECTRICAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Input |
Output |
||
|
Input Voltage Range |
90-264V AC |
Output Voltage |
12 - 30V DC |
|
Input Frequency |
47-63Hz |
Output Current |
4A(45VA max) |
|
Input Current |
0.79A(max) |
Output Tolerance |
5% |
|
|
|
Ripple & Noise |
1%p-p max |
|
|
|
Efficiency |
85% |
OUTPUT SPECIFICATIONS
SERIES NO. : SIE49
SWITCHING ADAPTOR
DESKTOP-INLET SOCKET
49 SERIES
|
PART NO. |
OUTPUT |
|
|
VOLT |
CURRENT (max) |
|
|
SIE49-1204000 |
12.0V |
4.00A |
|
SIE49-1503300 |
15.0V |
3.30A |
|
SIE49-2402100 |
24.0V |
2.10A |
|
SIE49-3001700 |
30.0V |
1.70A |
 |
 |
 |
 |
 |
 |
