GENERAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
0 to +40oC |
Operating Humidity |
20 to 90% RH |
|
Storage Temperatures |
-20 to +85oC |
Storage Humidity |
20 to 90% RH |
|
Hi-Pot Test |
MTBF |
||
|
Hi-Pot |
4242VDC for 1 minute |
MTBF |
50,000Hours at 25oC |
|
EMISSSION |
SAFETY |
||
|
EMI/EMC |
FCC |
Safety Approvals |
UL/CUL/GS/CCC/K-mark/PSE/ |
|
Safety Compliant |
UL 60950/EN 60950/IEC 60950 |
||
OUTPUT SPECIFICATIONS
SERIES NO. : SIE34
|
ELECTRICAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Input |
Output |
||
|
Input Voltage Range |
90-264V AC |
Output Voltage 1 |
See rating chart (+/-5% tolerance) |
|
Input Frequency |
47-63Hz |
Output Voltage 2 |
See rating chart (+/-5% tolerance) |
|
Input Current |
1.2A(max) |
Output Current |
See rating chart |
|
|
|
Ripple & Noise |
100mV/240mVp-p |
|
|
|
Efficiency |
75% |
SWITCHING ADAPTOR
DESKTOP-INLET SOCKET
34 SERIES
|
PART NO. |
OUTPUT1 |
OUTPUT2 |
||
|
VOLT |
CURRENT |
VOLT |
CURRENT |
|
|
SIE34-050200120200 |
+5V |
2.00A |
+12V |
2.00A |
 |
 |
 |
 |
 |
 |
