GENERAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
0 to +40oC |
Operating Humidity |
5 to 95% RH |
|
Storage Temperatures |
-40 to +85oC |
Storage Humidity |
5 to 95% RH |
|
Hi-Pot Test |
MTBF |
||
|
Hi-Pot |
4242VAC |
MTBF |
50,000Hours at 25oC |
|
EMISSSION |
SAFETY |
||
|
EMI/EMC |
FCC |
Safety Approvals |
UL/CUL/GS/CE/CB |
|
Safety Compliant |
UL 60950/EN 60950/IEC 60950 |
||
OUTPUT SPECIFICATIONS
SERIES NO. : SIE25
|
ELECTRICAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Input |
Output |
||
|
Input Voltage Range |
90-264V AC |
Output Voltage 1 |
See rating chart (+/-5% tolerance) |
|
Input Frequency |
47-63Hz |
Output Voltage 2 |
See rating chart (+/-5% tolerance) |
|
Input Current |
0.6A(max) |
Output Voltage 3 |
See rating chart (+/-5% tolerance) |
|
|
|
Output Current |
See rating chart |
|
|
|
Ripple & Noise |
1%p-p max |
|
|
|
Efficiency |
>65% |
SWITCHING ADAPTOR
DESKTOP-INLET SOCKET
25 SERIES
|
PART NO. |
OUTPUT1 |
OUTPUT2 |
OUTPUT3 |
|||
|
VOLT |
CURRENT |
VOLT |
CURRENT |
VOLT |
CURRENT |
|
|
SIE25-050250120080120030 |
+5V |
2.50A |
+12V |
0.80A |
-12V |
0.30A |
|
SIE25-050250150050150030 |
+5V |
2.50A |
+15V |
0.50A |
-15V |
0.30A |
|
SIE25-050250240080240030 |
+5V |
2.50A |
+12V |
0.80A |
-5V |
0.30A |
 |
 |
 |
 |
 |
 |
