SWITCHING  TRANSFORMER
EPC SERIES

side-bg11b
side-bg11
side-bg12
side-bg-crn1
page4s1
btn-blk
side-bg11
side-bg-crn
btn-co-j1
00002
SPECIFICATION AND MECHANICAL PHYSICAL DIMENSIONS
Part Number
Power max (W)
Freq. (KHz)
Ae
(mm2)
AW
(mm2)
A
(max)
B
(max)
C
(max)
D
(+/-0.5)
E
(+/-0.3)
F
(+/-0.3)
G(OD)
(+/-0.1)
No. of Pins
PTEPC130HA
8
100
12.5
11.2
14
14
8
10.5
2.5
2.5
0.7
10
PTEPC170HA
20
100
22.8
20.1
19
19
13
15
3.75
2.5
0.7
10
PTEPC190HA
27
100
22.7
29.3
21
21
13
16.25
3.75
2.5
0.7
11
PTEPC250HA
59
100
46.4
54.4
27
27
17
20
5
3.75
0.8
11
PTEPC250HB
59
100
46.4
54.4
27
27
17
20
5
3.5
0.8
12
PTEPC270HA
75
100
54.6
62.1
29
34
17
27.5
5
3.75
0.8
11
PTEPC270HB
75
100
54.6
32.4
29
34
17
25
3.75
-
0.8
14
PTEPC300HA
81
100
61
68.1
32
37
17
30
5
5
1
12
HA and HB stand for Horizontal Type
