GENERAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
0 to +40oC |
Operating Humidity |
20 to 95% RH |
|
Storage Temperatures |
-20 to +85oC |
Storage Humidity |
5 to 95% RH |
|
Hi-Pot Test |
MTBF |
||
|
Hi-Pot |
2545VDC/10mA/2SEC |
MTBF |
120,000Hours at 25oC |
|
EMISSION |
SAFETY |
||
|
EMI/EMC |
FCC |
Safety Approvals |
UL/CUL/PSE |
|
Safety Compliant |
UL 60950/EN 60950 |
||
SWITCHING ADAPTOR
WALLMOUNT
17 SERIES
OUTPUT SPECIFICATIONS
SERIES NO. : UP17
|
ELECTRICAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Input |
Output |
||
|
Input Voltage Range |
90-264V AC |
Output Voltage 1 |
See rating chart (+/-5% tolerance) |
|
Input Frequency |
47-63Hz |
Output Voltage 2 |
See rating chart (+/-5% tolerance) |
|
Input Current |
0.5A(max) |
Output Current |
See rating chart |
|
|
|
Ripple & Noise |
65mv/120mvp-p |
|
|
|
Efficiency |
>70% |
|
PART NO. |
OUTPUT1 |
OUTPUT2 |
||
|
VOLT |
CURRENT |
VOLT |
CURRENT |
|
|
UP17-050100120100 |
+5V |
1.00A |
+12V |
1.00A |
 |
 |
 |
 |
 |
 |
